Ever spent hours building a quad drone only to find the motors refuse to spin up—and even make no sound at all with certain settings? It’s a surprisingly common problem that can stump both beginners and seasoned builders. Let’s walk through why this happens and how you can finally get your 5-inch quad in the air.

Understanding Your Quad Drone Motor Problem

If your build works with PWM or Multishot but the motors “lag”—and doesn’t work at all with DSHOT—it points toward an issue between your flight controller (like the Speedybee F405V4) and the electronic speed controllers (ESCs). Here’s what that means in plain English:

– **PWM/Multishot** are older signal protocols—slower but more forgiving.
– **DSHOT** is digital and preferred for modern builds; it’s faster and more reliable, but picky about wiring and configuration.

When you only hear the first tone from your Brotherhobby 1300kv motors after plugging in the battery (and nothing else), it usually means the ESCs aren’t receiving complete instructions from the flight controller. According to Oscar Liang’s guide on DSHOT, this is often related to signal or firmware mismatches.

Step-by-Step Checklist to Fix Quad Drone Motors That Won’t Spin

Before you reach for a soldering iron or buy new parts, let’s go through a quick checklist:

• Firmware: Make sure your flight controller has the latest firmware installed. Betaflight is standard for most DIY drones.
• Signal Wiring: Double-check all motor signal wires between your FC and ESCs. Digital protocols like DSHOT are sensitive—one loose wire can stop everything.
• ESC Protocol Setting: In Betaflight Configurator, select DSHOT under “ESC/Motor Features.” Save and reboot.
• ESC Firmware: If possible, update your ESCs using BLHeliSuite. Some older or budget ESCs might not support all versions of DSHOT.
• Power Supply: Are you using a battery with enough voltage/amperage? Weak or old batteries will sometimes trigger odd errors.
• Tones: Only hearing one tone from each motor suggests incomplete initialization. The full sequence means power + valid signal.

If everything above checks out but you’re still stuck, try switching back to PWM/Multishot in Betaflight. If those work but feel “laggy,” it’s further proof something is off with digital communication.

Troubleshooting Deeper Issues With Speedybee F405V4 & DSHOT

The Speedybee F405V4 is popular because of its wireless configuration features—but even it isn’t immune to protocol headaches. Some common quirks include:

– **Incorrect resource mapping:** Sometimes motor outputs don’t match up in software; double-check resource remapping under CLI in Betaflight.
– **Bootloader bugs:** Rarely, flashing Betaflight can break communication unless you fully erase settings first.
– **ESC compatibility:** Not all ESCs play nicely with every flight controller at every protocol speed. Make sure both FC and ESC claim support for your target DSHOT version (GetFPV explains this well).
– **Signal inversion:** Certain boards need an inverted signal for some protocols; check documentation for both FC and ESC.

If you’re seeing lag or sluggish response even on PWM/Multishot, it could be as simple as enabling motor output filtering or increasing loop frequency in Betaflight—sometimes called “motor timing” or “update rate.” Small changes here can make big improvements to responsiveness.

A Builder’s Story — And What Finally Fixed It

One pilot shared their frustration after spending days troubleshooting why their shiny new build wouldn’t arm its motors on DSHOT. Everything looked fine until they realized one corner of their solder joints was cold—barely making contact. A quick reflow fixed everything instantly.

Another time, simply flashing both FC and ESCs together (after full erasure) made all four motors sing through their entire startup sequence for the first time. Sometimes it really comes down to starting fresh!

Quick Recap: How To Get Your Quad Drone Motors Spinning

• Check firmware versions on both FC & ESC
• Verify all wiring—especially signal wires
• Select correct protocol in Betaflight
• If stuck, try re-flashing firmware from scratch
• Use trusted guides like Oscar Liang’s blog
• If possible, swap in another known-good component (FC or ESC) as a test

The Takeaway — What Will You Try Next?

Getting stuck at the “motors won’t spin” stage can be frustrating—but it almost always comes down to signal issues or firmware settings that are easy enough to fix once you know what to look for. So what step will you try first?

If you’ve recently struggled with similar problems on your build—or found an unusual solution—share your experience! Every tip helps someone else get back in the air faster.
